ROUND AIR DUCT
ELBOWS
     Elbows produce with special machine. .Yuvarlak Specifications are galvanized, stainless or aluminium roll sheet.Special segment parts gives shape with special machine and clamp each other.

     Products are optional, as the paint and can be isolated from internal or external.

      TECHNICAL SPECIFICATIONS AND MOUNTING INFORMATION


     If wanted all the fittings are make without gasket. And also cost %10 reduced.
     Ýn textile, wood or paper industry elbows and other fittings make with flanges.

     Elbows shall be manufactured at any angle, standard angles; 90º, 60º, 45º, 30º, 15º. But non-standard angels are produced if it is in the project.
     Return radius "R" make same with diameter in standard."R=ØD". If you are prompted we can make R=1,5xØD, R=2xØD, R=2,5xØD, R=3xØD...
     The number of parts constituting the elbows according to the diameter is 4, 5 ve 6. Part depending on the number of requests are change to subject .
